General Meeting - March 13, 2010
Line



Our March 13, 2010 general meeting featured this SMD (Surface Mount Device) soldering exercise by Jim Pope, KGØPP:
(Everybody present got a chance to practice these soldering techniques!)
RFP RF Probe Kit
"QRPme's RF probe kit is about the easiest and simplest smd kit you can find that also performs a useful task. Containing only three 1206 sized smd parts and a fully silk screened solder masked circuit board, the kit is a fast build, and useful too! Use it to troubleshoot your malfunctioning QRP kit. The main difference in our kit and all the others is the lack of any enclosure or hardware! Your creativity is encouraged! In fact, we are having a little contest with this kit: build the kit & take a picture of the finished kit and another of the kit inside YOUR enclosure and send it to QRPme for adding to the 'Great RF Probe Contest' pages. The totally unbiased Official Team of Contest Judges will pick 3 winners using some form of convoluted rules and guidelines that I won't go into here (mainly 'cause we haven't thunk them up yet!) and award some truly stupendous prizes! Small $6 purchase required to enter... At this price, you can afford to buy more than one and give it away! RFP Probe Kit: $6.00 "
Our meeting location was generously provided by Milestone Technologies
10691 East Bethany Drive, Suite 800 Aurora, Colorado



Click on any of this page's "Thumbnail" images for a larger view



DVT
WØLMD's DVT antenna with N1FN
W0LMD
WØLMD
Practice
Ira's SMD soldering practice
Lunch
Lunch bunch



Watch our Low Down publication for more photos and articles!
